Heatflo - 87 Gallon (Extra High Output) Indirect Water Heater

Heatflo - 87 Gallon (Extra High Output) Indirect Water Heater

no reviews for this product. Login to place a review.

Heat-flo’s high efficiency indirect water heaters are made with quality stainless steel materials that provide excellent heat transfer and a longer tank life, as well as abundant water and low operating costs. Indirect water heaters work in conjunction with a boiler to heat the water that's circulated through the heat exchanger in the storage tank. Heat-flo offers extra high output coils in both the HF-85-XHO, with an 87-gallon tank, and the HF-115-XHO with a 115-gallon tank. Units can be banked together for applications with high water heating demands.

When paired with an high efficiency boiler, Heat-flo’s indirect water heaters can generate over 50% more hot water than many water heaters of similar size.

QUALITY DESIGN AND CONSTRUCTION

    *Tanks and coils are all stainless steel construction.
    *Large, smooth-wall coils deliver full output for years
     - no finned tubing to collect lime and sediment.
    *Over 2" of insulation, providing less than 1° / hr.
     heat loss.
    *Flexible thermoplastic jacket that will not corrode
     and resists denting.

EASY INSTALLATION

    *All connections are on top on the standard units for a
     neat, quick, and clean installation.
    *Brass drain and relief valves are factory installed.
    *A high quality thermal well comes standard.

RESIDENTIAL AND COMMERCIAL

    *Models are available in 60, 80 and 115 gallon tanks.
    *Bank together 80 and 115 gallon units for applications
     with high water heating demands.
    *Limited warranty residential installation, 5 year
     commercial.

TECH SPECS:

Capacity: 87gal
Coil Heating Surface: 28.7 SF
Domestic Water Connection: 11/2" - Top Connection
Boiler Water Connection: 11/2" - Top Connection
Height - top of tank: 62.3"
Diameter: 28"
Weight: 215 Lbs

Manufacturer Part # HF-85-XHO
In Store Description: 86G X-HIGH OUTPUT INDIR HEATFLO

U/M
Price
Part Number
HF85XHO
Manufacturer
DAVID GOODING
